This item is 3D-printed in durable PETG via FDM. Do not install in locations where surface temperatures may exceed 55°C (131°F). Because this product is 3D-printed, it may show subtle layer lines or small surface imperfections. These cosmetic variations are normal and do not affect function or performance.
It is not ETL or UL-listed and should not be used in applications where certified components are required by code. For those situations, we recommend using common off-the-shelf (COTS) parts. Our responsibility is limited exclusively to the replacement of any defective product. We are not liable for incidental, consequential, or indirect damages arising from use or misuse of this item.
Reolink TrackMix Junction Box Adapter - Type E
Regular price
$15.95
Regular price
-45%
$28.95
Sale price
$15.95
Couldn't load pickup availability
Mount a Reolink TrackMix Camera to an Electrical Box
Reolink Adapter Type E lets you mount a compatible Reolink TrackMix camera on a wall, ceiling, or soffit using common junction-box, outlet-box, and low-voltage-frame mounting patterns. The camera side matches Reolink mounting template 60.01.009.0006.
🌟 Why Choose This Adapter?
- Camera-specific fit: Designed from Reolink mounting template 60.01.009.0006.
- Two box patterns: Supports 3.5-inch junction-box and 3.28-inch outlet-box mounting patterns.
- Multiple mounting locations: Suitable for wall, ceiling, or soffit installation when the electrical box and camera installation permit it.
📹 Verified Camera Compatibility
- Current-generation Reolink TrackMix cameras using mounting template 60.01.009.0006
- Other Reolink hardware using mounting template 60.01.009.0006
🔩 Electrical-Box Compatibility
- 4-inch junction box: 3.5-inch diagonal spacing
- Outlet box or low-voltage frame: 3.28-inch vertical or horizontal spacing
📐 Specifications
- Electrical-box-side diameter: 127 mm (5 in)
- Overall height: 30 mm (1.18 in)
- Camera side: Shaped for Reolink mounting template 60.01.009.0006
📦 In The Box
- 1 Reolink Adapter Type E in the selected color
- 1 weatherproof gasket
Camera, original Reolink mounting hardware, and electrical-box screws are not included.
🛠️ Installation
Fasten the adapter to a compatible electrical box, place the gasket at the box side, then attach the camera’s original hardware to the camera side. Complete weather sealing according to the camera manufacturer’s instructions and applicable electrical requirements.
